Leuze
Leuze 50114209 IS 240PP/44-8N0 Inductive switch
Part number: 50114209
$205.85
/ Default Title
Ships in manufacturer lead time. Contact us for an ETA.
Sold as Default Title: 0 pieces per package · per piece.
Ships by truck freightThis package is heavy or oversized and ships by LTL truck freight instead of parcel. Contact us with delivery questions (liftgate, loading dock, lead time).
Need help selecting this part? Contact an applications specialist →
Typ. operating range limit Sn: 8 mm
Operating range Sa: 0 ... 6.4 mm
Supply voltage: 10 ... 30 V, DC
Digital switching outputs: 2 Piece(s)
Switching output 1: Transistor, PNP, NO contact – Antivalent
Switching output 2: Transistor, PNP, NC contact – Antivalent
Switching frequency: 1,400 Hz
Connection: Cable, 2,000 mm, 4 -wire
Design, housing: Cubic
Dimensions: 12 mm x 40 mm x 26 mm
Type of installation: Non-embedded/non-flush
Housing material: Plastic
Certifications: c UL US
Operating range Sa: 0 ... 6.4 mm
Supply voltage: 10 ... 30 V, DC
Digital switching outputs: 2 Piece(s)
Switching output 1: Transistor, PNP, NO contact – Antivalent
Switching output 2: Transistor, PNP, NC contact – Antivalent
Switching frequency: 1,400 Hz
Connection: Cable, 2,000 mm, 4 -wire
Design, housing: Cubic
Dimensions: 12 mm x 40 mm x 26 mm
Type of installation: Non-embedded/non-flush
Housing material: Plastic
Certifications: c UL US
