Leuze
Leuze 50139660 PRK25CL1.1/28-M12 Polarized retro-reflective photoelectric sensor
Part number: 50139660
$268.62
/ Default Title
Ships in manufacturer lead time. Contact us for an ETA.
Sold as Default Title: 0 pieces per package · per piece.
Ships by truck freightThis package is heavy or oversized and ships by LTL truck freight instead of parcel. Contact us with delivery questions (liftgate, loading dock, lead time).
Need help selecting this part? Contact an applications specialist →
Special version: Activation input
Operating range limit: 0.15 ... 25 m
Light source: Laser, Red
Protection class: 1
Shift angle: Typ. ± 1.5°
Supply voltage: 10 ... 30 V, DC
Digital switching outputs: 1 Piece(s)
Switching output 1: Transistor, NPN, Light switching
Switching frequency: 2,500 Hz
Connection: Connector, M12, PUR, 4 -pin
Design, housing: Cubic
Dimensions: 15 mm x 42.7 mm x 30 mm
Housing material: Plastic
Operational controls: 270° potentiometer
Ambient temperature, operation: -40 ... 60 °C
Degree of protection: IP 69K, IP 67
Operating range limit: 0.15 ... 25 m
Light source: Laser, Red
Protection class: 1
Shift angle: Typ. ± 1.5°
Supply voltage: 10 ... 30 V, DC
Digital switching outputs: 1 Piece(s)
Switching output 1: Transistor, NPN, Light switching
Switching frequency: 2,500 Hz
Connection: Connector, M12, PUR, 4 -pin
Design, housing: Cubic
Dimensions: 15 mm x 42.7 mm x 30 mm
Housing material: Plastic
Operational controls: 270° potentiometer
Ambient temperature, operation: -40 ... 60 °C
Degree of protection: IP 69K, IP 67
