Leuze
Leuze 50147923 LE25CI.XR1/2N Throughbeam photoelectric sensor receiver
Part number: 50147923
$362.97
/ Default Title
Ships in manufacturer lead time. Contact us for an ETA.
Sold as Default Title: 0 pieces per package · per piece.
Ships by truck freightThis package is heavy or oversized and ships by LTL truck freight instead of parcel. Contact us with delivery questions (liftgate, loading dock, lead time).
Need help selecting this part? Contact an applications specialist →
Application: Detection of products in bag packaging
Supply voltage: 10 ... 30 V, DC
Digital switching outputs: 2 Piece(s)
Switching output 1: Transistor, NPN, Light switching
Switching output 2: Transistor, NPN, Dark switching
Switching frequency: 100 Hz
Connection: Cable, 2,000 mm, 4 -wire
Design, housing: Cubic
Dimensions: 15 mm x 42.7 mm x 30 mm
Housing material: Plastic
Operational controls: 270° potentiometer
Ambient temperature, operation: -40 ... 60 °C
Degree of protection: IP 69K, IP 67
Supply voltage: 10 ... 30 V, DC
Digital switching outputs: 2 Piece(s)
Switching output 1: Transistor, NPN, Light switching
Switching output 2: Transistor, NPN, Dark switching
Switching frequency: 100 Hz
Connection: Cable, 2,000 mm, 4 -wire
Design, housing: Cubic
Dimensions: 15 mm x 42.7 mm x 30 mm
Housing material: Plastic
Operational controls: 270° potentiometer
Ambient temperature, operation: -40 ... 60 °C
Degree of protection: IP 69K, IP 67
