Leuze 50151542 HT25CI-650F/4P-M12 Diffuse sensor with background suppression
Part number: 50151542
$238.65
/ Default Title
Ships in manufacturer lead time. Contact us for an ETA.
Sold as Default Title: 0 pieces per package · per piece.
Ships by truck freightThis package is heavy or oversized and ships by LTL truck freight instead of parcel. Contact us with delivery questions (liftgate, loading dock, lead time).
Need help selecting this part? Contact an applications specialist →
Special version: Permanently set range
Operating range limit: 0 ... 0.65 m
Light source: LED, Infrared
Supply voltage: 10 ... 30 V, DC
Digital switching outputs: 2 Piece(s)
Switching output 1: Transistor, PNP, Light switching
Switching output 2: Transistor, PNP, Dark switching
Switching frequency: 1,000 Hz
Connection: Connector, M12, PUR, 4 -pin
Design, housing: Cubic
Dimensions: 15 mm x 42.7 mm x 30 mm
Housing material: Plastic
Ambient temperature, operation: -40 ... 60 °C
Degree of protection: IP 69K, IP 67
Operating range limit: 0 ... 0.65 m
Light source: LED, Infrared
Supply voltage: 10 ... 30 V, DC
Digital switching outputs: 2 Piece(s)
Switching output 1: Transistor, PNP, Light switching
Switching output 2: Transistor, PNP, Dark switching
Switching frequency: 1,000 Hz
Connection: Connector, M12, PUR, 4 -pin
Design, housing: Cubic
Dimensions: 15 mm x 42.7 mm x 30 mm
Housing material: Plastic
Ambient temperature, operation: -40 ... 60 °C
Degree of protection: IP 69K, IP 67
