Leuze
Leuze 63000309 S300-P13C1-M12-SB Safety position switch
Part number: 63000309
$119.88
/ Default Title
Ships in manufacturer lead time. Contact us for an ETA.
Sold as Default Title: 0 pieces per package · per piece.
Ships by truck freightThis package is heavy or oversized and ships by LTL truck freight instead of parcel. Contact us with delivery questions (liftgate, loading dock, lead time).
Need help selecting this part? Contact an applications specialist →
Contact allocation: 2NC + 1NO, Slow-action contact
Connection: Connector, M12, Plastic, 8 -pin
Dimensions: 40 mm x 39 mm x 97 mm
Housing material: Plastic, Glass fiber reinforced (PPS), self-extinguishing
Switch type: Interlock device without guard interlocking, ISO 14119
Switching direction: One side, Both sides
Approach actuation directions: 4 x side (90°), 360°
Degree of protection: IP 67
Certifications: IMQ, c UL US
Connection: Connector, M12, Plastic, 8 -pin
Dimensions: 40 mm x 39 mm x 97 mm
Housing material: Plastic, Glass fiber reinforced (PPS), self-extinguishing
Switch type: Interlock device without guard interlocking, ISO 14119
Switching direction: One side, Both sides
Approach actuation directions: 4 x side (90°), 360°
Degree of protection: IP 67
Certifications: IMQ, c UL US
