Wago - 272-304

WAGO

WAGO - 272-304

Part number: 51125822

$3.72

Ships in manufacturer lead time. Contact us for an ETA.

51125822

Request a quote

Datasheet (PDF)

Need help selecting this part? Contact an applications specialist →

WAGO component - equivalent to 272304

Specifications

  • Primary brand: WAGO
  • GTIN code: 4044918439688
  • Order code / Manufacturer SKU: 272-304
  • Manufacturer product status: Commercialized
  • Equivalent to: 272304
  • EAN code: 4044918439688
  • Manufacturer description: Power supply connector; push-button on both sides; without snap-in mounting feet; without ground contact; 4-pole; 2.5mm2; white
  • Manufacturer product specifications: Electrical data - Ratings per IEC/EN - Ratings per -- IEC/EN 60664-1|Electrical data - Ratings per IEC/EN - Rated voltage (III/2) -- 400V|Electrical data - Ratings per IEC/EN - Rated impulse withstand voltage (III/2) -- 4kV|Electrical data - Ratings per IEC/EN - Rated current -- 18A|Electrical data - Ratings per IEC/EN - Legend (ratings) -- (III / 2) Overvoltage category III / Pollution degree 2|Connection data - Clamping units -- 16|Connection data - Total number of potentials -- 4|Connection data - Number of connection types -- 1|Connection data - Connection 1 - Connection technology -- PUSH WIRE|Connection data - Connection 1 - Solid conductor -- 0.5...1.5mm2 / 20...16 AWG|Connection data - Connection 1 - Strip length -- 8...9mm / 0.31...0.35"|Connection data - Connection 1 - Pole number -- 4|Connection data - Connection 2 - Solid conductor -- 0.5...2.5mm2 / 20...14 AWG|Physical data - Width -- 38.5mm / 1.516"|Physical data - Height -- 19mm / 0.748"|Physical data - Depth -- 24.5mm / 0.965"|Material data - Color -- white|Material data - Material group -- I|Material data - Insulation material (main housing) -- Polyamide (PA66)|Material data - Flammability class per UL94 -- V0|Material data - Fire load -- 0.309MJ|Material data - Weight -- 12.7g|Commercial data - eClass 10.0 -- 27-14-11-04|Commercial data - eClass 9.0 -- 27-14-11-04|Commercial data - ETIM 9.0 -- EC000446|Commercial data - ETIM 8.0 -- EC000446|Commercial data - ECCN -- NO US CLASSIFICATION|Commercial data - PU (SPU) -- 500 pcs|Commercial data - Packaging type -- bag|Commercial data - Country of origin -- DE|Commercial data - GTIN -- 4044918439688|Commercial data - Customs tariff number -- 85369010000|Environmental Product Compliance - RoHS Compliance Status -- Compliant;No Exemption
  • Location of origin: Germany
  • Level 1 category: Cabling systems
  • Level 2 category: Connectors & Inserts

Commercial data

  • Country of origin: DE
  • Customs tariff number: 85369010000
  • ECCN: NO US CLASSIFICATION
  • eCl@ss 10.0: 27-14-11-04
  • eCl@ss 9.0: 27-14-11-04
  • ETIM 8.0: EC000446
  • ETIM 9.0: EC000446
  • GTIN: 4044918439688
  • Packaging type: bag
  • PU (SPU): 500 pcs

Connection data

  • Clamping units: 16
  • Connection 1 - Connection technology: PUSH WIRE®
  • Connection 1 - Pole number: 4
  • Connection 1 - Solid conductor: 0.5 … 1.5 mm² / 20 … 16 AWG
  • Connection 1 - Strip length: 8 … 9 mm / 0.31 … 0.35 inches
  • Connection 2 - Solid conductor: 0.5 … 2.5 mm² / 20 … 14 AWG
  • Number of connection types: 1
  • Total number of potentials: 4

Electrical data

  • Ratings per IEC/EN - Legend (ratings): (III / 2) ≙ Overvoltage category III / Pollution degree 2
  • Ratings per IEC/EN - Rated current: 18A
  • Ratings per IEC/EN - Rated impulse withstand voltage (III/2): 4kV
  • Ratings per IEC/EN - Rated voltage (III/2): 400V
  • Ratings per IEC/EN - Ratings per: IEC/EN 60664-1

Environmental Product Compliance

  • RoHS Compliance Status: Compliant,No Exemption

Material data

Physical data

  • Depth: 24.5 mm / 0.965 inches
  • Height: 19 mm / 0.748 inches
  • Width: 38.5 mm / 1.516 inches
