WAGO - 283-908

Shield terminal block with 1-deck/level + center marking slot - WAGO (283 series) - White - 1 shield-through pole (1S) / 2-wires (1 clamp + 1 clamp) (1+1) - for 0.2mm2...16mm2 / for #24AWG...#6AWG - with CAGE CLAMP spring connections - DIN-35 rail (35 x 15 / 35 x 7.5) mounting (12mm width) - equivalent to 283908

Specifications

• Primary brand: WAGO
• Functions: Shield terminal block
• Design: 1-deck/level|center marking slot
• Poles: 1 shield-through pole (1S)
• Temperature: Processing temperature -35°C...+85°C|Continuous operating temperature -60°C...+105°C
• Color: White
• Connection capacity: 2-wires (1 clamp + 1 clamp) (1+1)
• Connection type: CAGE CLAMP spring connections
• Cross-section: for 0.2mm2...16mm2 fine stranded or solid conductors|for #24AWG...#6AWG fine stranded or solid conductors
• Mounting mode: DIN-35 rail (35 x 15 / 35 x 7.5)
• Dimensions: H94.5mm x W12mm x D37.5mm
• Net Width (mm): 12mm
• Material: Polyamide (PA) 66
• eClass code: 27-14-11-41
• GTIN code: 4045454084578
• ETIM code: EC000901
• Customs Tariff Number: 85369010000
• Order code / Manufacturer SKU: 283-908
• Manufacturer product status: Commercialized
• Equivalent to: 283908
• EAN code: 4045454084578
• Compliant with standard(s): RoHS compliant|material group I|V-0 flammability rating
• Location of origin: Germany
• Level 1 category: Electrical components
• Level 2 category: Terminal blocks
• Product title: Shield terminal block - 1-deck/level - WAGO

Commercial data

• Country of origin: DE
• Customs tariff number: 85369010000
• ECCN: NO US CLASSIFICATION
• eCl@ss 10.0: 27-14-11-41
• eCl@ss 9.0: 27-14-11-41
• ETIM 8.0: EC000901
• ETIM 9.0: EC000901
• GTIN: 4045454084578
• Packaging type: box
• PU (SPU): 20 pcs

Connection data

• Clamping units: 2
• Connection 1 - Actuation type: Operating tool
• Connection 1 - Connectable conductor materials: Copper
• Connection 1 - Connection technology: CAGE CLAMP^®
• Connection 1 - Fine-stranded conductor: 0.2 … 16 mm² / 24 … 6 AWG
• Connection 1 - Solid conductor: 0.2 … 16 mm² / 24 … 6 AWG
• Connection 1 - Strip length: 16 … 17 mm / 0.63 … 0.67 inches
• Connection 1 - Wiring direction: Front-entry wiring
• Number of levels: 1
• Total number of potentials: 1

Electrical data

• Ratings per IEC/EN - Nominal voltage (III/3): 800V
• Ratings per IEC/EN - Rated current: 76A
• Ratings per IEC/EN - Rated impulse withstand voltage (III / 3): 8kV
• Ratings per IEC/EN - Ratings per: IEC/EN 60947-7-2

Environmental Product Compliance

• CAS-No.: 7439-92-1
• REACH Candidate List Substance: Lead
• RoHS Compliance Status: Compliant,No Exemption
• SCIP notification number (Austria): 44919da6-0591-49c4-b8b9-ce87ca1d0dc0
• SCIP notification number (Belgium): 53afe1c4-73dd-430d-bc53-25e3fe6b1250
• SCIP notification number (Bulgaria): 1237d60c-cd01-4fe9-bb59-e4a5a26ed823
• SCIP notification number (Czech Republic): eeb300ec-13db-46f8-980e-cf44ae712e63
• SCIP notification number (Denmark): c7300ac4-07ce-4683-9819-45486d0d9bce
• SCIP notification number (Finland): ca337ce1-e3ce-41da-85c7-6d0eae928390
• SCIP notification number (France): 71628dd8-98c6-4bdb-ab5d-084a47a4be2b
• SCIP notification number (Germany): 1c305480-dc62-4a36-8fd8-b02cb4823fcb
• SCIP notification number (Hungary): 500d2b02-7e04-4bd2-a2f6-197e8a4c3224
• SCIP notification number (Italy): 770fbe62-8990-4371-8d99-18f810360895
• SCIP notification number (Netherlands): 76534a4e-7ad5-42f4-9342-6d897881fa4b
• SCIP notification number (Poland): 47bc7aa3-4293-420e-962b-6328b9fd32fa
• SCIP notification number (Romania): fe94fc76-ad23-4338-8caa-e1db7d3daccf
• SCIP notification number (Sweden): 10401bb6-36fc-4497-b0e3-6f3f91df60c3

Environmental requirements

• Continuous operating temperature: -60 … +105 °C
• Processing temperature: -35 … +85 °C

Material data

• Color: white
• Fire load: 0.502MJ
• Flammability class per UL94: V0
• Insulation material (main housing): Polyamide (PA66)
• Material group: I
• Note (material data):
  Information on material specifications can be found here

• Weight: 46.6g

Mechanical data

• Design: horizontal type
• Marking level: Center marking
• Mounting type: DIN-35 rail

Physical data

• Depth from upper-edge of DIN-rail: 37.5 mm / 1.476 inches
• Height: 94.5 mm / 3.72 inches
• Width: 12 mm / 0.472 inches
