WAGO - 788-754

Replacement plug-in basic solid-state / static relay (SSR) module with green LED - 2-wire connection - WAGO (788 series) - single-pole / single-phase / 1-pole (1P) - control voltage 10-30Vdc (24Vdc nom.) - Rated voltage 0-35Vdc (24Vdc nom.) output - Rated current 5A (continuous) - with plug-in connections - Plug-in mounting - equivalent to 788754

Specifications

• Primary brand: WAGO
• Functions: Replacement plug-in basic solid-state / static relay (SSR) module
• Design: green LED|2-wire connection
• Poles: single-pole / single-phase / 1-pole (1P)
• Frequency: 3kHz switching frequency
• Rated current: 5A (continuous)
• Rated Voltage (DC): 0-35Vdc (24Vdc nom.) output
• Connection type: plug-in connections
• Control Voltage (DC): 10-30Vdc (24Vdc nom.)
• Mounting mode: Plug-in
• Response time: (switching ON) 50μs / 0.00005s|(switching OFF) 250μs / 0.00025s
• Dimensions: H15.7mm x W12.7mm x D29mm
• Ambient air temperature for operation: -30°C...+80°C
• Ambient air temperature for storage: -40°C...+100°C
• GTIN code: 4055143919258
• ETIM code: EC001504
• Customs Tariff Number: 85364190890
• Order code / Manufacturer SKU: 788-754
• Manufacturer product status: Commercialized
• Equivalent to: 788754
• EAN code: 4055143919258
• Compliant with standard(s): EN 61000-6-2|EN 61000-6-3|EN 61010-2-201|EN 61373|General approvals|- UL - Underwriters Laboratories Inc. - UL 508 - certificate E340707|RoHS compliant
• Location of origin: Germany
• Level 1 category: Automation components
• Level 2 category: Control components
• Level 3 category: Control relays
• Product title: Replacement plug-in basic solid-state / static relay (SSR) module - WAGO

Commercial data

• Country of origin: DE
• Customs tariff number: 85364190890
• ECCN: NO US CLASSIFICATION
• ETIM 8.0: EC001504
• ETIM 9.0: EC001504
• GTIN: 4055143919258
• Packaging type: Box
• PU (SPU): 20 pcs

Environmental Product Compliance

• RoHS Compliance Status: Compliant,No Exemption

Environmental requirements

• Ambient temperature (operation at U_N): -30 … +80 °C
• Ambient temperature (storage): -40 … +100 °C

Material data

• Note (material data):
  Information on material specifications can be found here

• Weight: 4g

Mechanical data

• Mounting type: Pluggable module

Notes

• Note: Optocouplers and solid state relays are designed for use in signal processing networks that are not supplied directly by the low-voltage power supply network.

Physical data

• Depth: 29 mm / 1.142 inches
• Height from the surface: 15.7 mm / 0.618 inches
• Width: 12.7 mm / 0.5 inches

Safety and protection

• Dielectric strength (control/load circuit) (AC, 1 min): 3.51 kVrms

Standards and specifications

• Standards/specifications: EN 61010-2-201|EN 61000-6-2|EN 61000-6-3|EN 61373

Technical data

• Control circuit - Input voltage range (high level): 10 … 30 VDC
• Control circuit - Input voltage range (low level): 0 … 9 VDC
• Control circuit - Nominal input current at U_N: 11 mA
• Control circuit - Nominal input voltage U_N: 24 VDC
• Load circuit - Circuit type: 2-wire connection
• Load circuit - Limiting continuous current: 5 A
• Load circuit - Nominal output voltage: 24 VDC
• Load circuit - Output voltage range: 0 … 35 VDC
• Load circuit - Switching current (min.): 1 mA
• Load circuit - Switching frequency: ≤ 3 kHz
• Load circuit - Turn-off time: ≤ 250 µs
• Load circuit - Turn-on time: ≤ 50 µs
• Load circuit - Voltage drop: ≤ 0.3 VDC
• Signaling - Status indicator: Green LED
