Leuze 63001025 MC388-S2R10-A Magnetically coded sensor
Part number: 63001025
$160.95
/ Default Title
Ships in manufacturer lead time. Contact us for an ETA.
Sold as Default Title: 0 pieces per package · per piece.
Ships by truck freightThis package is heavy or oversized and ships by LTL truck freight instead of parcel. Contact us with delivery questions (liftgate, loading dock, lead time).
Need help selecting this part? Contact an applications specialist →
Contact allocation: 2NO
Connection: Cable with wire-end sleeves, 10,000 mm, PUR, 4 -wire
Dimensions: 25 mm x 13 mm x 88 mm
Housing material: Plastic, Glass fiber reinforced (PPS), self-extinguishing
External actuator: Magnetically coded
Cut-out point (OFF), min.: 19 mm
Assured cut-out distance (Sar), min.: 22 mm
Assured cut-in distance (Sao), max.: 9 mm
Degree of protection: IP 67
Certifications: c UL US, TÜV Süd (with suitable safety relay)
Connection: Cable with wire-end sleeves, 10,000 mm, PUR, 4 -wire
Dimensions: 25 mm x 13 mm x 88 mm
Housing material: Plastic, Glass fiber reinforced (PPS), self-extinguishing
External actuator: Magnetically coded
Cut-out point (OFF), min.: 19 mm
Assured cut-out distance (Sar), min.: 22 mm
Assured cut-in distance (Sao), max.: 9 mm
Degree of protection: IP 67
Certifications: c UL US, TÜV Süd (with suitable safety relay)
